Fig. 6.3-3a and b. Longitudinal section of a shoot apex of pine (Pinus). Pines, like all seed plants, have shoot apical meristems without prominent single apical cells. Instead, the shoot apical meristem consists of numerous small cells, no one of which has any special importance. This apex is a rather typical size for seed plant apices, and the youngest leaf primordium visible is on the right, an older primordium is on the left (with red-stained tannins causing the epidermis to be dark red). Most cells here are light red (due to their prominent nuclei dominating the cells), but there are many tannin cells in the young pith and cortex.


Figure b shows the pine apex at higher magnification. Pines and other conifers have shoot apical meristems with a mantle-core organization. By definition, if cells in the outermost layer undergo periclinal divisions (the new wall is parallel to the surface of the apex), then the layer is a mantle, not a tunica. This micrograph shows several cells produced by a periclinal division -- the cluster of about 5 cells near the top right of the apex, where the outermost cells are very short (arrow). All cells interior to the mantle make up the core. Notice that near the sides and bottom of the meristem, the cells tend to be aligned in rows whereas in the very center, the cells are in no apparent pattern. The central cells are the central mother cells (CMC), the aligned cells make up the peripheral zone (PZ; near the edges) and the pith-rib meristem (PRM; the tannin cells and cells near them). There is no obvious boundary between the peripheral zone and the pith-rib meristem.
