Fig. 7.3-7. Longitudinal section of wood of magnolia (Magnolia tripetala). This section contains a compound perforation plate in face view. The seven large white ovals are the actual perforations, separated from each other by six bars of perforation plate wall material that was not digested away by the cells as they finished their differentiation. Because the perforations are separated by parallel bars, this is a scalariform perforation plate. The region between the two large horizontal arrows is the full perforation plate; although it consists of secondary wall material, it has taken up very little stain and is unusually pale, not as dark red as most other walls present here. Just above the perforation plate, you can see that the vessel elements have broad pits -- almost wide enough to say they are scalariform, a bit too wide to call them circular. Each has a white center surrounded by a pale light gray rim: the white is the pit aperture, the gray is the pit border (where the secondary wall has arched up away from the primary wall, creating the pit chamber). The pale pink between each pit is the area where the secondary wall is attached to the primary wall.
