Fig. 10.3-5. Magnification of stoma in fig leaf (Ficus). This is a sunken stoma, sunken below the plane of the epidermis. It appears as if the guard cells (arrows) are part of a hypodermis or the mesophyll, but they are epidermis cells (without exception, guard cells form only in the epidermis), it is just that the epidermis itself lines this small depression that has the stoma at the bottom of it. A paradermal section that contained most of the ordinary cells of the epidermis would miss all the stomata completely.

            By being sunken at the bottom of this depression, air in the depression is slightly protected from wind, and any molecule of water that escapes from the stoma may remain in the depression long enough to actually bounce back into the leaf rather than being blown away. See Fig. 10.23 on page 182 in Plant Anatomy (Mauseth) for more details.
